Chapter 1. Introduction
3
Requirements
Console
(KE6900) One DVI compatible monitors capable of the highest possible
resolution
(KE6940) Two DVI compatible monitors capable of the highest possible
resolution
A USB mouse
A USB keyboard
Microphone and speakers
Computers
The following equipment must be installed on each computer that is to be
connected to the system:
(KE6900) One DVI port
(KE6940) Two DVI ports
USB Type A port
Audio ports
Cables
For optimal signal integrity and to simplify the setup, we strongly
recommend that you only use the high quality custom USB KVM Cable
that is provided with this package.
Software
The minimum hardware and software requirements for the computer running
the Matrix Manager software are:
Processor: Intel or AMD processor 1 GHz or above
RAM: 2GB or above
HDD: 16GB or above
Web browser
Java Runtime Environment (JRE) 6 with update 11 or higher
Operating System Requirements:
Windows 2000, XP, Vista, 2003, 2008, 7 and 8.1
Linux (Ubuntu, CentOS, Fedora, SUSE)
