KE6900 / KE6940 User Manual
154
Switch Port Command
The formula for Switch Port commands is as follows:
Command + Output + Num1 + Input + Num2 + Mode + Stream +
Connect + [Enter]
1. For example, if you want to switch the User Station’s connection to
Transmitter (192.168.0.20), type the following:
sw i192.168.0.20 [Enter]
2. For example, if you want to disconnect the User Station from its
Transmitter connections, type the following:
sw off [Enter]
3. For example, if you want to connect User Station (192.168.0.99) to
Transmitter (192.168.0.79) with exclusive access to stream video and
audio, type the following:
sw o192.168.0.99 i192.168.0.79 exclusive video audio on [Enter]
4. For example, to disconnect User Station (192.168.0.11) from the video
stream and return it to the OSD menu, type the following:
sw o192.168.0.11 off [Enter]
5. For example, to disconnect User Station (192.168.0.09) from the video
stream and logout the OSD, type the following:
sw o192.168.0.09 logout [Enter]
6. For example, to disconnect the User Station’s USB stream, type the
following:
sw usb off [Enter]
7. For example, to switch the User Station to the 5th Transmitter listed in the
command line interface, type the following:
sw i@5 exclusive all on [Enter]
8. For example, to switch the User Station to the 7th Transmitter listed in the
command line interface with echo command 4312, type the following:
sw i@7 exclusive all on e4312
9. For example, to switch User Station (192.168.0.12) to the 14th Transmitter
listed in the command line interface with occupy access to stream video
audio and USB, type the following:
sw o192.168.0.12 i@14 occupy video audio usb on [Enter]
