Chapter 13. RS-232 Commands
155
The following tables show the possible values for the Switch Port commands:
Command Description
sw Switch port command
Output Description
o Output port command (RX)
Num1 Description
xx Output port
xx: User Station ID or IP address
@zz List #
zz: 1~99
To use the 4th User Station listed
in the command line interface,
type: o@4
Input Description
i Input command (TX)
Num2 Description
yy Input port
yy: Transmitter ID or IP address
@zz List #
zz: 1~99
To use the 8th Transmitter listed
in the command line interface,
type: i@8
Mode Description
exclusive Sets the Access Mode to
exclusive.
share Sets the Access Mode to share.
occupy Sets the Access Mode to occupy.
viewonly Sets the Access Mode to view
only. If the mode is omitted, view
only is used by default.
Stream Description
video Sets the video source stream
audio Sets the audio source stream
serial Sets the serial source stream
