![Aten KE6900 [153/222] Backup](/views2/1211143/page153/bg99.png)
Chapter 11. Maintenance
139
Backup
To back up system configuration settings, do the following:
1. (Optional) In the Backup panel, provide a password for the backup file.
Note: Providing a password is a security feature – if you provide a
password, you will need to give the same password in order to
restore the configuration settings from this file.
2. Click Backup.
3. In the dialog box that comes up, Click Save to save the configuration file
(System.conf) to a location on your hard disk.
4. Navigate to the directory where you want to save the file and click Save.
Restore
To restore system configuration settings, do the following:
1. In the Restore panel, click Browse.
2. Navigate to the directory where the backup file is located and select it.
3. When you return to the Backup/Restore page enter the password you set
when the backup file was created.
Note: If you did not set a password for the file, leave the field blank.
4. Click Restore.
5. Click OK to confirm that you want to restore the configuration data.
When the Restore procedure is in process, a message stating that the
Matrix Manager will restart will appear. After a short while the Matrix
Manager closes and refreshes at the log in screen. When it comes back up
the configuration settings that were restored from the backup file are in
effect.
