Chapter 3. OSD Operation
37
After entering the information, click Save.
Transmitter
Video Attributes
To set the Transmitter’s video settings:
Video Type: Select the DVI video connector being used by the
display: Digital (DVI-D) or Digital (DVI-I).
Color Depth: Select the number of bits to use for the color
depth: 24, 16, or 8. This is the number of bits used to describe
the color of a single pixel. A bit depth determines the number of
colors that can be displayed at one time.
Bandwidth Limit: Select the maximum bandwidth that the
Transmitter can use to transmit video over the network. A lower
bandwidth setting transmits lower quality video; a higher
bandwidth setting sends higher quality video but this can affect
network speed.
Video Quality: Select the video quality to use. 5 is the highest
video quality, and 1 is the lowest video quality. Options are: 1~5.
Background Refresh: Sets how often the Transmitter
refreshes the background image on the connected display.
Options are to refresh every 256,128, 64, 32,16, or 0 frames.
Beeper Check this box to allow the device to beep every time a
configuration change is made.
Occupy Timeout Set a time threshold for devices whose Access Mode has been
set to Occupy (see Allowed Access Mode, page 122). If there is
no activity from the User Station occupying the port for the
amount of time set here, the User Station is timed out and the
port is released. The first User Station to send keyboard or
mouse input after the port has been released gets to occupy the
port. Input a value from 1 to 240 seconds.
Item Description
