KE6900 / KE6940 User Manual

Properties Port OS: Use the drop-down menu to select the operating

system of the computer connected to the Transmitter.

OS Language: Use the drop-down menu to select the

operating system language of the computer connected to the

Transmitter.

Enable Multicast Video: Check this box to allow a broadcast of

the Transmitter’s video signal to be sent out to multiple User

Stations.

Enable Multicast Audio: Check this box to allow a broadcast

of the Transmitter’s audio signal to be sent out to multiple User

Stations.

EDID Mode Selection: EDID contains a display's basic

information and is used by the source device to utilize the best

resolution across different monitors. Select how you want the

source device to acquire the display's EDID:

 Default: EDID is set to the default ATEN configuration.

 Auto: Checks the EDID of all connected displays and uses

the best resolution for all displays.

 Manual: Manually set the EDID configuration from the

Connections Page (see page 41).

 Remix: Checks the EDID of all connected displays and the

source device uses the best common resolution for all

displays.

Enable Media Select which type of media the Transmitter can stream to User

Stations: Video, Audio, USB, and RS232.

RS232 Settings Configure the serial device settings for the Transmitter. The

default settings are:

Baud Rate: 9600

Parity: None

Data Bits: 8 bits

Stop bits: 1 bit

Flow Control: None

Manager

Address

Set the IP address and Port number of the computer running

the Matrix Manager software. The default port number is 9110.

Item Description
