KE6900 / KE6940 User Manual
24
Note: See Default IP Addresses, page 24, for the preconfigured
factory-default settings.
Subnet Mask – sets the subnet mask for the KE6900 / KE6940. Key in
a valid subnet mask value.
Note: The default setting is 255.255.255.0
Default Gateway– sets the default gateway for the KE6900 / KE6940.
Key in a valid default gateway.
6. Click Save.
Exit OSD
To exit the OSD, press [Esc] on the keyboard, click Logout; tap the Scroll
Lock key twice; or return to the OSD main page and press the front panel OSD
pushbutton (Receiver only).
At this point the Receiver can connect to the Transmitter to access the remote
computer (see Connecting, page 40 for instructions).
Default IP Addresses
The preconfigured factory-default IP addresses for the KE6900 / KE6940 units
are as follows:
KE6900T / KE6940T – 192.168.0.61
KE6900R / KE6940R – 192.168.0.60
