Aten KE6900 [141/222] In each case the user s access rights are the ones assigned that were assigned when the user of group was created on the matrix manager

Chapter 9. System

127

 Use the same Group name on both the RADIUS server and the

Matrix Manager.

 Use the same Username/Group name on both the RADIUS server

and the Matrix Manager.

In each case, the user’s access rights are the ones assigned that were

assigned when the User of Group was created on the Matrix Manager.

 LDAP / AD Authentication and Authorization Settings:

To allow authentication and authorization for the Matrix Manager via

LDAP / AD, refer to the information in the table, below:

Item Action

Enable Put a check in the Enable checkbox to allow LDAP / AD

authentication and authorization.

Enable SSL Put a check in the Enable checkbox to allow SSL connections.

LDAP Server IP

and Port

Fill in the IP address and port number for the LDAP / AD server.

 You can use the IPv4 address, the IPv6 address or the domain

name in the LDAP Server field.

 For LDAP, the default port number is 389.

Timeout Set the time in seconds that the Matrix Manager waits for an

LDAP / AD server reply before it times out.

Admin DN Consult the LDAP / AD administrator to ascertain the appropriate

entry for this field. For example, the entry might look like this:

ou=kn4132,dc=aten,dc=com

Admin Name Key in the LDAP administrator’s username.

Password Key in the LDAP administrator’s password.

Search DN Set the distinguished name of the search base. This is the

domain name where the search starts for user names.
