Aten KE6900 [90/222] Deleting a user station

KE6900 / KE6940 User Manual

Deleting a User Station

To delete a User Station:

1. Select the User Station you want to delete.

2. Click Move Out.

The device list updates with the remaining User Stations. The User Station you

deleted will appear on the Unmanaged User Stations main page and Sidebar

menu.
