Aten KE6900 [203/222] Optional rack mounting

Appendix

189

Optional Rack Mounting

For convenience and flexibility, two optional rack mounting kits are available

as shown in the following table:

Dual Rack Mounting

The 2X-021G Dual Rack Mounting Kit installs two KE6900 units side by side

in 1U of server rack space.

1. Remove four screws from the KE6900 units and then use the same screws

to secure the units together with the link bracket.

(Continues on next page.)

Mounting Type Model

KE69 Dual Rack Mount Kit 2X-021G

KE69 Single Rack Mount Kit 2X-031G

Link Bracket
