KE6900 / KE6940 User Manual

Properties Port OS: Use the drop-down menu to select the operating

system of the computer connected to the Transmitter.

OS Language: Use the drop-down menu to select the

operating system language of the computer connected to the

Transmitter.

Enable Multicast Video: Check this box to allow a broadcast of

the Transmitter’s video signal to be sent to multiple User

Stations.

Enable Multicast Audio: Check this box to allow a broadcast

of the Transmitter’s audio signal to be sent to multiple User

Stations.

EDID Mode Selection: EDID contains a display's basic

information and is used by the source device to utilize the best

resolution across different monitors. Select how you want the

source device to acquire the display's EDID:

 Default: EDID is set to the default ATEN configuration.

 Auto: Checks the EDID of all connected displays and uses

the best resolution for all displays.

 Manual: Manually set the EDID configuration from the User

Station’s OSD (see Manual EDID, page 42).

 Remix: Checks the EDID of all connected displays and the

source device uses the best common resolution for all

displays.

Enable Media Select which source type the Transmitter can stream: Video,

Audio, USB and RS232.

RS232 Settings Configure the serial device settings for the Transmitter. The

default settings are:

Baud Rate: 9600

Parity: None

Data Bits: 8 bits

Stop bits: 1 bit

Flow Control: None

Manager

Address

Set the Manger IP address and Manager Port number of the

computer running the Matrix Manager software. The default port

number is 9110.

Item Description
