Functional concept ESIEN05-04
2–10 Part 2 – Functional Description
3
1
2
4
5
1.7 Automatic Restart
Purpose The purpose of the auto-restart function is to automatically resume the same operating mode as when
the unit was operating when the power supply is restored after a power failure.
Do not use the "Automatic Restart" function to daily start/stop the unit.
Precautions when
turning OFF power
Q When you have to turn OFF the power supply in order to carry out maintenance, make sure to turn
the remote control's ON/OFF switch OFF firstly.
Q If you turn OFF the power supply while the remote control's ON/OFF switch is still ON, the
"automatic restart function" automatically starts the indoor fan immediately and the outdoor unit fan
starts automatically 3 minutes after the power supply is turned back ON.
Q Do not start/stop the unit by disconnecting the power supply.Stop the unit by stop commando from
the remote control or optional controller before disconnecting the power supply. Be sure that the
compressor and the outdoor fans are stopped before disconnecting the power supply so the
"Refrigerant Recovery function" has been finished correctly.
Q When restarting the unit after the power was disconnected for a longer period leave the unit OFF
with the power supply connected for about half an hour.
