Specifications ESIEN05-04
1–52 Part 1 – System Outline
3
11
4
5
2.8 FUQ – B
Technical
specifications
The table below contains the technical specifications.
Electrical
specifications
The table below contains the electrical specifications.
Specification FUQ71BUV1B FUQ100BUV1B FUQ125BUV1B
Heat exchanger Rows x stages x fin pitch 3 x 6 x 1.5 mm 3 x 8 x 1.5 mm
Face area 0.265 m² 0.353 m²
Tube type N-Hix
Fin type Multi louver
Fan Air flow rate cooling (high) 19.0 m³/min 29.0 m³/min 32.0 m³/min
Air flow rate cooling (low) 14.0 m³/min 21.0 m³/min 23.0 m³/min
Air flow rate heating (high) 19.0 m³/min 29.0 m³/min 32.0 m³/min
Air flow rate heating (low) 14.0 m³/min 21.0 m³/min 23.0 m³/min
Qty x model (rotor) 1 x QTS48A10M 1 x QTS50B15M
Qty x model (motor) 1 x D16P45R23 1 x D17P90J23
Fan speed 2 steps
Fan type Turbo fan
Refrigerant Type R410A
Safety and functional devices
Fan motor thermal protector:
ON: 130
+/- 5
°C
OFF: 83
+/- 20
°C
Air filter Resin net (with mold resistant)
Temperature control Microcomputer control
Weight Unit 25 kg 31 kg
Specification FUQ71BUV1B FUQ100BUV1B FUQ125BUV1B
Unit Phase 1~
Voltage 220-240 V
Frequency 50 Hz
Power consumption 180 W 289 W
Nominal running current _
Fan motor FLA (Full load amps) 0.6 A 1.0 A
No. of motors x output 1 x 45 W 1 x 90 W
