ESIEN05-04 Wiring Diagrams
Part 1 – System Outline 1–71
3
1
4
5
33H Float switch Wired remote control
A1P Printed circuit board BS1 ON/OFF button
C1R Capacitor (Fan) BS2 Timer mode start/stop button
F1U Fuse (5A, 250V) BS3, BS8 Programming time button
F1T Thermal fuse (152°C) (M1F embedded) BS4, BS9 Temperature setting button
HAP Light emitting diode (Service monitor-green) BS6 Operation mode selector button
M1F Motor (Fan) BS7 Timer ON/OFF button
M1P Motor (Drain pump) BS11 Fan speed control button
R1T Thermistor (Air) BS12 Inspection/test operation button
R2T Thermistor (Liquid) BS14 Filter sign reset button
R3T Thermistor (Coil) H1P Light emitting diode (Service monitor-red)
RyF1-4 Magnetic relay (Fan) LCD Liquid cristal display
RyP Magnetic relay (Drain pump) SS1 Selector switch (Main/sub)
SS1 Selector switch (Emergency)
T1R Power supply transformer (220~240V/21.8V) Connector for optional parts
X1M Terminal strip X60A, X61A Connector (Interface adapter for Sky Air/US
series)
X2M Terminal strip
RC Signal receiver circuit X33A Connector (adapter for wiring)
TC Signal transmission circuit X35A Connector (Group control adapter)
X40A Connector (Remote ON/OFF, Forced OFF)
adapter for wiring
RyC, RyF Magnetic relay
