Daikin FAQ100BVV1B [200/381] Malfunctioning capacity setting aj
![Daikin FUQ125BUV1B [200/381] Malfunctioning capacity setting aj](/views2/1697514/page200/bgc8.png)
Error Codes ESIEN05-04
3–38 Part 3 – Troubleshooting
3
1
3
4
5
2.6 Malfunctioning Capacity Setting (
AJ
)
Error code AJ
LED indications The table below shows the LED indications.
Error generation The error is generated when the following conditions are fulfilled:
Causes The possible causes are:
Q Malfunctioning capacity setting adapter connection
Q Malfunctioning indoor unit PCB.
Capacity setting
adapter
The capacity is set in the PCB’s memory IC. A capacity setting adapter that matches the capacity of
the unit is required in the following case:
In case the indoor PCB installed at the factory is for some reason changed at the installation site, the
capacity will not be contained in the replacement PCB. To set the correct capacity for the PCB you
have to connect a capacity setting adapter with the correct capacity setting to the PCB. The capacity
setting for the PCB will become the capacity setting of the adapter because the capacity setting
adapter has priority.
Operation HAP (green) HBP (green)
Normal
cc
Malfunctioning
cc
Condition Description
1
Q The unit is in operation.
Q The PCB’s memory IC does not contain the capacity code.
Q The capacity setting adapter is not connected.
2
Q The unit is in operation.
Q The capacity that is set, does not exist for that unit.
