ESIEN05-04 Specifications
Part 1 – System Outline 1–53
3
1
4
5
2.9 FAQ – B
Technical
specifications
The table below contains the technical specifications.
Electrical
specifications
The table below contains the electrical specifications.
Specification FAQ71BUV1B FAQ100BUV1B
Heat exchanger Rows x stages x fin pitch 2 x 16 x 1.4 mm 2 x 12 x 1.4 mm
Face area 0.289 m² 0.332 m²
Tube type Hi-XA N-Hix
Fin type Multi louver
Fan Air flow rate cooling (high) 19.0 m³/min 23.0 m³/min
Air flow rate cooling (low) 15.0 m³/min 19.0 m³/min
Air flow rate heating (high) 19.0 m³/min 23.0 m³/min
Air flow rate heating (low) 15.0 m³/min 19.0 m³/min
Qty x model (rotor) 1 x QCL9886M 1 x QCL1163MA +
1 x QCL1163MB
Qty x model (motor) 1 x
(ARW30R8P43DA)
1 x D09P49A23
Fan speed 2 steps
Fan type Cross flow fan
Refrigerant Type R410A
Safety and functional devices
Fan motor thermal
protector:
OFF: 130
+/- 5
°C
ON: 83
+/- 20
°C
Air filter Resin net (mildew proof)
Temperature control Microcomputer control
Weight Unit 13 kg 26 kg
Specification FAQ71BUV1B FAQ100BUV1B
Unit Phase 1~
Voltage 220-240 V
Frequency 50 Hz
Power consumption 68 W 101 W
Nominal running current _
Fan motor FLA (Full load amps) 0.4 A
No. of motors x output 1 x 43 W 1 x 49 W
