ESIEN05-04 Wiring Diagrams
Part 1 – System Outline 1–65
3
1
4
5
S1L Float switch Receiver/display unit (attached to infrared remote control)
A1P Printed circuit board A2P, A3P Printed circuit board
C1R Capacitor (M2F) BS ON/OFF button
HAP Light emitting diode (Service monitor-green) H1P Light emitting diode (on-red)
M1A Motor (Swing flap) H2P Light emitting diode (timer-green)
M2F Motor (Indoor fan) H3P Light emitting diode (filter sign-red)
M3P Motor (Drain pump) H4P Light emitting diode (defrost-orange)
Q1F Thermo switch (M2F embedded) SS1 Selector switch (Main/Sub)
R1T Thermistor (Air) SS2 Selector switch (Wireless address set)
R2T Thermistor (Liquid)
RyP Magnetic relay (M3P) adapter for wiring
SS1 Selector switch (Emergency) RyC, RyF Magnetic relay
T1R Transformer (220V~240V/22 V)
X1M Terminal strip (Power) Connector for optional parts
X2M Terminal strip (Control) X60A, X61A Connector (Interface adapter for Sky Air series)
PC Phase control circuit X33A Connector (adapter for wiring)
RC Signal receiver circuit X35A Connector (Group control adapter)
TC Signal transmission circuit X40A Connector (Remote ON/OFF, Forced OFF)
Wired remote control
SS1 Selector switch (Main/Sub)
