Disassembly and Maintenance ESIEN05-04
5–32 Part 5 – Disassembly and Maintenance
3
1
55
4
Disconnect the
connector for fan motor.
Q For FCQ71D : Direct
connector
Q For FCQ100~
140D: Relay
connector
5
Remove the grounding
wire mounting screw.
6
Remove the switch box
fixing screw.
7
Tilt the switch box in the
direction shown by the
arrow, then draw the
entire switch box out.
(Status after removal)
Step
Procedure Points
Switch box fixing screw
Fan motor
Grounding wire
Inverter PC board
(for RZP100~140D models only)
Power supply PC board
Control PC board
