Functional concept ESIEN05-04
2–22 Part 2 – Functional Description
3
1
2
4
5
1.17 Fan and Flap Operations
Cooling operation The table below contains the fan and flap operations.
(*) LL operation on cassette type units
Heating operation The table below contains the fan and flap operations.
Function In… Fan Flap (FCQ and
FHQ)
Flap (FAQ) Remote control
indication
Thermostat ON
in Dry Keep
Mode
Swing operation L Swing Swing Swing
Airflow direction setting Set position Set position Set position
Thermostat
OFF in Dry
Keep Mode
Swing operation OFF Horizontal Horizontal Swing
Airflow direction setting Set position Set position Set position
Thermostat
OFF in Cooling
Mode
Swing operation Set Horizontal Horizontal Swing
Airflow direction setting Set position Set position Set position
Stop (Error) Swing operation OFF Horizontal Downward ---
Airflow direction setting Set position Downward
Freeze-preven-
tion
Swing operation OFF(*) Horizontal Horizontal Swing
Airflow direction setting Set position Set position Set position
Function In… Fan Flap (FCQ and
FHQ)
Flap (FAQ) Remote control
indication
Hot start after
defrost
Swing operation OFF Horizontal Horizontal Swing
Airflow direction setting Set position
Defrost Swing operation Swing
Airflow direction setting Set position
Thermostat
OFF
Swing operation LL Swing
Airflow direction setting Set position
Hot start after
thermostat OFF
(cold air pre-
vention)
Swing operation Swing
Airflow direction setting Set position
Stop (error) Swing operation OFF Fully closed (hori-
zontal)
---
Airflow direction setting Fully closed
Overload ther-
mostat OFF
Swing operation LL Horizontal Swing
Airflow direction setting Set position
