ESIEN05-04 Functional concept
Part 2 – Functional Description 2–15
3
2
4
5
1
1.11 PMV Control
Applicable units All inverter R410A sky-air
Outline When the automatic mode is selected on the remote-controller, the unit will automatically activate the
PMV control.
The PMV index is a calculated average comfort level.
Refer to ISO 7730 for details.
Function An optimized indoor temperature will be calculated using the following inputs:
Q Outdoor air temperature
Q Indoor air temperature
Q remote control set temperature
In practice, the set point will be moved with 1 or 2 degrees whenever the conditions change. This will
result in a combination of power saving and increased comfort level.
PMV control can be disabled by changing the field settings:
From: 11(21)-4-01 to: 11(21)-4-02
