Field Settings ESIEN05-04
4–24 Part 4 – Commissioning and Test Run
3
1
4
5
3.7 Setting the Filter Counter
Mode No. 10 or 20
First code No. 0
When the filter counter indication time is set to ON, set the second code No., according to the table
below
Fan speed setting at
thermostat OFF
When the cool/heat thermostat is OFF, you can stop the indoor unit fan by switching the setting to
“Fan OFF”. This setting is used as a countermeasure against odour, for example for barber shops and
restaurants.
You can switch the fan speed to the set fan speed when the heating thermostat is OFF. This setting is
called “Set Fan Speed” . Default the fan speed is set LL to prevent cold draft.
Note: That a combination of modes 11 (21) and 12 (22) is required to enable following settings:
Unit Mode No. First code No. Second code No. Contamination
01 02
light heavy
FCQ
10 or 20 0
±2500 hrs ±1250 hrs
FFQ ±2500 hrs ±1250 hrs
FHQ ±2500 hrs ±1250 hrs
FUQ ±2500 hrs ±1250 hrs
FAQ ±200 hrs ±100 hrs
FBQ ±2500 hrs ±1250 hrs
FDQ, FDEQ ±2500 hrs ±1250 hrs
Mode No. - First code No. Second code No.
01 02 03
Second
code No.
01 Cool: Set Speed
Head: LL Speed
Cool: Set Speed
Head: Set Speed
Cool: Set Speed
Head: Continu-
ously OFF
02 Cool: OFF + moni-
toring at set speed
Heat: OFF + moni-
toring at LL speed
Cool: OFF + moni-
toring at set speed
Heat: Set speed
Cool: OFF +moni-
toring at set speed
Heat: OFF + moni-
toring at OFF
12 (22) - 3
12 (21) - 2
