Specifications ESIEN05-04
1–46 Part 1 – System Outline
3
11
4
5
2.2 FCQ – B
Technical
specifications
The table below contains the technical specifications.
Electrical
specifications
The table below contains the electrical specifications.
Specification FCQ35B7V1 FCQ50B7V1 FCQ60B7V1 FCQ71B7V3B FCQ100B7V3B FCQ125B7V3B
Heat exchanger Rows x stages x fin pitch 2 x 8 x 1.5 mm 2 x 12 x 1.5 mm
Face area 0.331 m² 0.497 m²
Tube type HIXA diam. 7 HiXSS diam. 7
Fin type Rhombus
Fan Air flow rate cooling (high) 14 m³/min 15 m³/min 18 m³/min 18 m³/min 28 m³/min 31 m³/min
Air flow rate cooling (low) 10 m³/min 11 m³/min 14 m³/min 14 m³/min 21 m³/min 24 m³/min
Air flow rate heating (high) 14 m³/min 15 m³/min 18 m³/min 18 m³/min 28 m³/min 31 m³/min
Air flow rate heating (low) 10 m³/min 11 m³/min 14 m³/min 14 m³/min 21 m³/min 24 m³/min
Qty x model (rotor) 1 x QTS46B14M 1 x QTS46A17M
Qty x model (motor) 1 x 19NFB6079 1 x 19NFB6078
Fan speed 2 steps (direct drive)
Fan type Turbo fan
Refrigerant Type R410A
Safety and functional devices Inline fuse (250V 5A)
Fan motor thermal protector
OFF: 130
+/- 5
°C
ON: 83
+/- 20
°C
OFF: 140
+/- 5
°C
ON: 45
+/- 15
°C
Drain pump thermal fuse
Air filter Resin net (with mold resistant) - in decoration panel
Temperature control Computerized control Microprocessor thermostat for cooling and heating
Weight Unit 23 kg 27.0 kg
Specification FCQ35B7V1 FCQ50B7V1 FCQ60B7V1 FCQ71B7V3B FCQ100B7V3B FCQ125B7V3B
Unit Phase 1~
Voltage 230V
Frequency 50 Hz
Power consumption 140 W 161 W _
Nominal running current
Fan motor FLA (Full Load Amps) 0.6 A 1.0 A
No. of motors x output 1 x 45 W 1 x 90 W
