DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

MLD Snooping Settings

Users can configure the settings for MLD snooping.

To view the following window, click L2 Features > L2 Multicast Control > MLD Snooping > MLD Snooping

Settings, as show below:

Figure 7-54 MLD Snooping Settings window

The fields that can be configured are described below:

Parameter Description

MLD Snooping State

Click to enable or disable the MLD snooping state.

Max Learning Entry Value

(1-1024)

Enter the maximum learning entry value.

Click the Apply button to accept the changes made for each individual section.

Click the Edit button to configure the MLD Snooping Parameters Settings for a specific entry.

Click the

Modify Router Port

link to configure the MLD Snooping Router Port Settings for a specific entry.

After clicking the Edit button, the following page will appear:

Figure 7-55 MLD Snooping Parameters Settings window

The fields that can be configured are described below:

Parameter Description

Query Interval (1-65535)

Specify the amount of time in seconds between general query transmissions. The

default setting is 125 seconds.

Max Response Time (1-

25)

The maximum time in seconds to wait for reports from listeners. The default setting

is 10 seconds.

Robustness Value (1-7)

Provides fine-tuning to allow for expected packet loss on a subnet. The value of the

robustness variable is used in calculating the following MLD message intervals:

Group listener interval - Amount of time that must pass before a multicast router

decides there are no more listeners of a group on a network.
