DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

411

Address

provisioned.

New Backup IP

Address

Tick the check box and enter IP address of the backup switch that the AP to be

provisioned.

Profile ID

Use the drop-down menu to select the profile ID to be used when provisioning.

Click the Apply button to accept the changes made.

Click the Delete button to remove the entry.

Click the Provision the AP button to perform provisioning.

Advanced Configuration

Global

This window is used to configure wireless advanced settings.

To view this window, click Administration > Advanced Configuration > Global as shown below:

Figure 3-22 Global General window

The fields that can be configured are described below:

Parameter Description

Peer Group ID

Enter a peer group ID to configure wireless switches as peers. Peer switches share

some information about APs and allow L3 roaming among them.

Client Roam Timeout

(secs)

Enter a time in second to determine how long to keep an entry in the Associated

Client Status list after a client has disassociated.

Ad Hoc Client Status

Timeout (hours)

Enter a time in hour to determine how long to keep an entry in the Ad Hoc Client

Status list.

AP Failure Status

Timeout (hours)

Enter a time in hour to determine how long to keep an entry in the AP

Authentication Failure Status list.

MAC Authentication

Mode

Select the global action to take on wireless clients in the white-list or black-list.

white-list – Specify that any wireless clients with MAC addresses, specified in the

Known Client database and not explicitly denied access, are granted access. If the

MAC address is not in the database then the access to the client is denied.

black-list - Select this option to specify that any wireless clients with MAC
