DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
203
Figure 11-16 Authenticator Session Statistics window
The fields that can be configured are described below:
Parameter Description
Time Interval
Use the drop-down menu to select the interval.
Click the OK button to accept the changes made.
NOTE: The user must first globally enable Authentication Mode in the 802.1X Global Settings
window before initializing ports. Information in this window cannot be viewed before enabling
the authentication mode for either Port-based or MAC-based.
Authenticator Diagnostics
This window is used to display the authenticator diagnostics information.
To view this window, click Security > 802.1X > Authenticator Diagnostics as shown below:
