DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

current subnet should be sent. This is usually the address of a router or a host acting

as an IP gateway. If your network is not part of an intranet, or you do not want the

Switch to be accessible outside your local network, you can leave this field

unchanged.

Click the Apply button to accept the changes made.

Interface Settings

Users can display the Switch’s current IP interface settings.

To view the following window, click Management > IP Interface > Interface Settings, as show below:

Figure 6-8 Interface Settings window

The fields that can be configured are described below:

Parameter Description

Interface Name

Enter the name of the IP interface to search for.

Click the Find button to locate a specific entry based on the information entered.

Click the Add button to add a new entry based on the information entered.

Click the Delete All button to remove all the entries listed.

Click the IPv4 Edit button to edit the IPv4 settings for the specific entry.

Click the IPv6 Edit button to edit the IPv6 settings for the specific entry.

Click the Delete button to remove the specific entry.

NOTE: To create IPv6 interfaces, the user has to create an IPv4 interface then edit it to IPv6.

Click the Add button to see the following window.

Figure 6-9 IPv4 Interface Settings window

The fields that can be configured are described below:

Parameter Description

IP Interface Name

Enter the name of the IP interface being created.

IPv4 Address

Enter the IPv4 address used.

Subnet Mask

Enter the IPv4 subnet mask used.
