DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

VLAN Name

Enter the VLAN Name used.

Interface Admin State

Use the drop-down menu to enable or disable the Interface Admin State.

Secondary Interface

Tick the check box to use this Interface as a Secondary Interface. When the primary

IP is not available, the VLAN will switch to the secondary interface. It will switch back

when the primary IP was recovered.

Click the Apply button to accept the changes made.

Click the <<Back button to discard the changes made and return to the previous window.

Click the IPv4 Edit button to see the following window.

Figure 6-10 IPv4 Interface Settings – Edit window

The fields that can be configured are described below:

Parameter Description

Get IP From

Use the drop-down menu to specify the method that this Interface uses to acquire an

IP address.

Interface Name

Enter the name of the IP interface being configured.

IPv4 Address

Enter the IPv4 address used.

Subnet Mask

Enter the IPv4 subnet mask used.

VLAN Name

Enter the VLAN Name used.

IPv4 State

Use the drop-down menu to enable or disable IPv4 State.

Interface Admin State

Use the drop-down menu to enable or disable the Interface Admin State.

Click the Apply button to accept the changes made.

Click the <<Back button to discard the changes made and return to the previous window.

Click the IPv6 Edit button to see the following window.

Figure 6-11 IPv6 Interface Settings window

The fields that can be configured or displayed are described below:
