DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
289
Figure 13-19 Ethernet OAM Event Log window
The fields that can be configured are described below:
Parameter Description
Port
Use the drop-down menu to select the port number to view.
Port List
Enter a list of ports. Tick the All Ports check box to select all ports.
Click the Find button to locate a specific entry based on the information entered.
Click the Clear button to clear all the information entered in the fields.
Ethernet OAM Statistics
The window is used to show ports Ethernet OAM statistics information.
To view this window, click OAM > Ethernet OAM > Ethernet OAM Statistics, as shown below:
