DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
21
Command Logging Settings
This window is used to enable or disable the command logging settings.
To view this window, click System Configuration > Command Logging Settings, as shown below:
Figure 5-20 Command Logging Settings window
The fields that can be configured are described below:
Parameter Description
Command Logging State
Use the radio buttons to enable or disable the function.
Click the Apply button to accept the changes made.
NOTE: When the switch is under the booting procedure, all configuration commands will not be
logged. When the user uses AAA authentication to logged in, the user name should not be
changed if the user has used the Enable Admin function to replace its privilege.
