DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

206

NOTE: The user must first globally enable Authentication Mode in the 802.1X Global Settings

window before initializing ports. Information in this window cannot be viewed before enabling

the authentication mode for either Port-based or MAC-based.

RADIUS

Authentication RADIUS Server Settings

The RADIUS feature of the Switch allows the user to facilitate centralized user administration as well as providing

protection against a sniffing, active hacker.

To view this window, click Security > RADIUS > Authentication RADIUS Server Settings as shown below:

Figure 11-22 Authentication RADIUS Server Settings window

The fields that can be configured are described below:

Parameter Description

Index Choose the desired RADIUS server to configure: 1, 2 or 3 and select the IPv4

Address.

IPv4 Address

Set the RADIUS server IP address.

IPv6 Address

Set the RADIUS server IPv6 address.

Authentication Port (1-

65535)

Set the RADIUS authentic server(s) UDP port which is used to transmit

RADIUS data between the Switch and the RADIUS server. The default port is

1812.

Accounting Port (1-65535)

Set the RADIUS account server(s) UDP port which is used to transmit RADIUS

accounting statistics between the Switch and the RADIUS server. The default

port is 1813.

Timeout (1-255)

Set the RADIUS server age-out, in seconds.

Retransmit (1-20)

Set the RADIUS server retransmit time, in times.

Key

Set the key the same as that of the RADIUS server.

Confirm Key

Confirm the key the same as that of the RADIUS server.

Click the Apply button to accept the changes made.
