D-Link DWS-3160-24TC [212/505] Radius accounting settings

DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

207

RADIUS Accounting Settings

This window is used to configure the state of the specified RADIUS accounting service.

To view this window, click Security > RADIUS > RADIUS Accounting Settings as shown below:

Figure 11-23 RADIUS Accounting Settings window

The fields that can be configured are described below:

Parameter Description

Network

When enabled, the Switch will send informational packets to a remote RADIUS server

when 802.1X and WAC port access control events occur on the Switch.

Shell

When enabled, the Switch will send informational packets to a remote RADIUS server

when a user either logs in, logs out or times out on the Switch, using the console, Telnet,

or SSH.

System

When enabled, the Switch will send informational packets to a remote RADIUS server

when system events occur on the Switch, such as a system reset or system boot.

Click the Apply button to accept the changes made.

RADIUS Authentication

Users can display information concerning the activity of the RADIUS authentication client on the client side of the

RADIUS authentication protocol.

To view this window, click Security > RADIUS > RADIUS Authentication as shown below:
