DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
453
Any – All packets are considered to match the specified class and no additional
input information is needed.
IP DSCP – Select this to choose IP DSCP Keyword in the next window. The
packet’s DSCP must match the selected keyword.
IP Precedence – Select this to choose Precedence Value in the next window. The
packet’s DSCP must match the selected value.
IP TOS – Select this to enter the ToS bits and its mask in the next window. the
packet’s Type of Service bits in the IP header must match the entered value.
Protocol - Select this to choose a protocol in the next window. A packet’s layer 4
protocol must match the selected protocol.
Reference Class – Select to choose a class to start referencing for criteria in the
next window.
Source IP Address – Select to enter an IP address and its mask in the next
window. A packet’s source IP address must match the entered IP address and its
mask.
Source Layer4 Port – Select this to choose protocol keyword in the next window. A
packet’s TCP/UDP source port must match the selected port.
Source MAC Address – Select this to enter a MAC address and its mask in the
next window. A packet’s source MAC address must match the address entered.
VLAN – Select this to enter a VLAN ID in the next window.
When Class Layer 3 Protocol is IPv6, the following selections display in the drop-
down menu.
Destination IPv6 Address – Select this to enter an IPv6 prefix and its length in the
next window. A packet’s destination IPv6 prefix must match the address entered.
Destination Layer4 Port – Select this to choose protocol keyword in the next
window. A packet’s TCP/UDP destination port must match the selected port.
Any – All packets are considered to match the specified class and no additional
input information is needed.
Flow Label – Select this to enter the flow label value in the next window.
IP DSCP – Select this to choose IP DSCP Keyword in the next window. The
packet’s DSCP must match the selected keyword.
Protocol – Select this to choose a protocol in the next window. A packet’s layer 4
protocol must match the selected protocol.
Reference Class – Select to choose a class to start referencing for criteria in the
next window.
Source IPv6 Address – Select this to enter an IPv6 prefix and its length in the next
window. A packet’s source port IPv6 prefix must match the address entered.
Source Layer4 Port – Select this to choose protocol keyword in the next window. A
packet’s TCP/UDP source port must match the selected port.
Click the Add Match Criteria to see the criteria configuration for the class.
Click the Apply button to accept the changes made.
Click the Cancel button to discard the configuration.
Policy Configuration
This window is used to associate a collection of classes with one or more policy statements.
To view this window, click QoS > Differentiated Services > Policy Configuration as shown below:
