DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
481
configuration
Successful Enable Admin
through Web authenticated by
AAA server
Successful Enable Admin through Web from
<userIP> authenticated by AAA server
<serverIP> (Username: <username> )
Informational
Enable Admin failed through
Web authenticated by AAA
server
Enable Admin failed through Web from
<userIP> authenticated by AAA server
<serverIP> (Username: <username> )
Warning
Enable Admin failed through
Web due to AAA server timeout
or improper configuration
Enable Admin failed through Web from
<userIP> due to AAA server timeout or
improper configuration (Username:
<username>)
Warning
Successful Enable Admin
through Web(SSL)
authenticated by AAA server
Successful Enable Admin through Web(SSL)
from <userIP> authenticated by AAA server
<serverIP> (Username: <username> )
Informational
Enable Admin failed through
Web(SSL) authenticated by AAA
server
Enable Admin failed through Web(SSL) from
<userIP> authenticated by AAA server
<serverIP> (Username: <username> )
Warning
Enable Admin failed through
Web(SSL) due to AAA server
timeout or improper
configuration
Enable Admin failed through Web(SSL) from
<userIP> due to AAA server timeout or
improper configuration (Username:
<username>)
Warning
Successful Enable Admin
through TELNET authenticated
by AAA server
Successful Enable Admin through TELNET
from <userIP> authenticated by AAA server
<serverIP> (Username: <username>)
Informational
Enable Admin failed through
TELNET authenticated by AAA
server
Enable Admin failed through TELNET from
<userIP> authenticated by AAA server
<serverIP> (Username: <username> )
Warning
Enable Admin failed through
TELNET due to AAA server
timeout or improper
configuration
Enable Admin failed through TELNET from
<userIP> due to AAA server timeout or
improper configuration (Username:
<username>)
Warning
Successful Enable Admin
through SSH authenticated by
AAA server
Successful Enable Admin through SSH from
<userIP> authenticated by AAA server
<serverIP> (Username: <username> )
Informational
Enable Admin failed through
SSH authenticated by AAA
server
Enable Admin failed through SSH from
<userIP> authenticated by AAA server
<serverIP> (Username: <username> )
Warning
Enable Admin failed through
SSH due to AAA server timeout
or improper configuration
Enable Admin failed through SSH from
<userIP> due to AAA server timeout or
improper configuration (Username:
<username> )
Warning
Port Security
port security is exceeded to its
maximum learning size and will
not learn any new address
Port security violation (MAC address:
<macaddr> on port: <portNum>)
Warning
MBAC
A host fails to pass the
authentication
MAC-based Access Control unauthenticated
host(MAC: <macaddr>, Port <portNum>, VID:
<vid>)
Critical
The authorized user number on
a port reaches the max user
limit.
Port <portNum> enters MAC-based Access
Control stop learning state.
Warning per port
The authorized user number on
a port is below the max user
limit in a time interval
Port <portNum> recovers from MAC-based
Access Control stop learning state.
Warning per port
The authorized user number on
whole device reaches the max
user limit.
MAC-based Access Control enters stop
learning state.
Warning per system
The authorized user number on
whole device is below the max
user limit in a time interval
MAC-based Access Control recovers from
stop learning state.
Warning per system
A host passes the authentication
MAC-based Access Control host login
successful (MAC: <macaddr>, port:
<portNum>, VID: <vid>)
Informational
A host is aged out
MAC-based Access Control host aged out
(MAC: <macaddr>, port: <portNum>, VID:
<vid>)
Informational
IMPB
Unauthenticated IP address
encountered and discarded by
IP IP-MAC port binding
Unauthenticated IP-MAC address and
discarded by IMPB (IP: <ipaddr>, MAC:
<macaddr>, Port <portNum>)
Warning
Dynamic IMPB entry is conflict
with static ARP
Dynamic IMPB entry conflicts with static
ARP(IP: <ipaddr>, MAC: <macaddr>, Port
Warning
