DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

To view the following window, click Management > SNMP Settings > SNMPv6 Host Table Settings, as show

below:

6-41 SNMPv6 Host Table Settings

The fields that can be configured are described below:

Parameter Description

Host IPv6 Address

Type the IPv6 address of the remote management station that will serve as the

SNMP host for the Switch.

User-based Security

Model

SNMPv1 – Specifies that SNMP version 1 will be used.

SNMPv2 – Specifies that SNMP version 2 will be used.

SNMPv3 – Specifies that SNMP version 3 will be used.

Security Level NoAuthNoPriv – To specify that the SNMP version 3 will be used, with a NoAuth-

NoPriv security level.

AuthNoPriv – To specify that the SNMP version 3 will be used, with an Auth-NoPriv

security level.

AuthPriv – To specify that the SNMP version 3 will be used, with an Auth-Priv security

level.

Community String /

SNMPv3 User Name

Type in the community string or SNMP V3 user name as appropriate.

Click the Apply button to accept the changes made.

Click the Delete button to remove the specific entry.

RMON Settings

On this page the user can enable or disable remote monitoring (RMON) for the rising and falling alarm trap feature

for the SNMP function on the Switch.

To view the following window, click Management > SNMP Settings > RMON Settings, as show below:

Figure 6-42 RMON Settings window

The fields that can be configured are described below:

Parameter Description

RMON Rising Alarm Trap

Enable this option to use the RMON Rising Alarm Trap Feature.
