D-Link DWS-3160-24TC [31/505] Ip interface

DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

Figure 6-6 IPv6 Neighbor Settings window

The fields that can be configured are described below:

Parameter Description

Interface Name

Enter the interface name of the IPv6 neighbor.

Neighbor IPv6 Address

Enter the neighbor IPv6 address.

Link Layer MAC

Address

Enter the link layer MAC address.

Interface Name Enter the name of the IPv6 neighbor. Tick the All check box to search for all current

interfaces on the Switch.

State

Use the drop-down menu to select All, Address, Static, or Dynamic. When the user

selects address from the drop-down menu, the user will be able to enter an IP

address in the space provided next to the state option.

Click the Add button to add a new entry based on the information entered.

Click the Find button to locate a specific entry based on the information entered.

Click the Clear button to clear all the information entered in the fields.

IP Interface

System IP Address Settings

The IP address may initially be set using the console interface prior to connecting to it through the Ethernet. The

Web manager will display the Switch’s current IP settings.

NOTE: The Switch’s factory default IP address is 10.90.90.90 with a subnet mask of 255.0.0.0 and a

default gateway of 0.0.0.0.
