DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
436
Switch Provisioning
This window is used to configure switch provisioning.
To view this window, click Administration > Advanced Configuration > Switch Provisioning as shown below:
Figure 3-40 Switch Certificate Request window
The fields that can be configured are described below:
Parameter Description
Switch IP Address
Enter the IP address of the peer switch.
Click the Start button to perform switch certificate request.
After clicking the Switch Provisioning tab, the following page will appear:
Figure 3-41 Switch Provisioning window
