DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
462
Figure 2-3 Download Firmware – HTTP window
The fields that can be configured are described below:
Parameter Description
Destination File
Enter the location of the Destination File.
Source File Enter the location of the Source File or click the Browse button to navigate to the
firmware file for the download.
Click Download to initiate the download.
Upload Firmware
The following window is used to upload firmware from the Switch.
Upload Firmware To TFTP
This page allows the user to upload firmware from the Switch to a TFTP Server.
Figure 2-4 Upload Firmware – TFTP window
The fields that can be configured are described below:
Parameter Description
TFTP Server IP
Enter the TFTP server IP address used.
IPv4
Click the radio button to enter the TFTP server IP address used.
IPv6
Click the radio button to enter the TFTP server IPv6 address
used.
Destination File
Enter the location and name of the Destination File.
Source File
Enter the location and name of the Source File.
Click Upload to initiate the upload.
Download Configuration
The following window is used to download the configuration file for the Switch.
