DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
484
database full
full client MAC: <macaddr> dropped
Peer Switch Wireless peer Switch discovered
Wireless peer switch: <ipaddr> discovered
Informational
Wireless peer Switch failed
Wireless peer switch: <ipaddr> failed
Warning
Wireless peer Switch protocol
version unknown
Wireless peer switch: <ipaddr> protocol
version: <version> unknown
Warning
Wireless peer switch Managed
AP database limit has exceeded
Wireless peer switch <ipaddr> managed AP
database full AP MAC: <macaddr> dropped
Warning
Managed AP
Wireless managed AP
discovered
Wireless managed AP MAC: <macaddr>
discovered
Informational
Wireless managed AP failed
Wireless managed AP MAC: <macaddr> failed
Warning
Wireless managed AP protocol
version unknown
Wireless managed AP MAC: <macaddr>
protocol version:<string> unknown
Warning
Wireless managed AP
Association failed
Wireless managed AP MAC: <macaddr>
Association failed
Warning
Wireless managed AP
Authentication failed
Wireless managed AP MAC: <macaddr>
Authentication failed
Warning
RF Scan
Wireless RF scan rogue-AP
detected
Wireless RF scan rogue-AP MAC: <macaddr>
AP MAC: <macaddr> Radio If: <int> SSID:
<ssid> detected
Informational
Wireless RF scan new Neighbor
AP detected
Wireless RF scan new Neighbor AP MAC:
<macaddr> AP MAC: <macaddr> Radio If:
<int> SSID: <ssid> detected
Informational
Wireless RF scan new Client
detected
Wireless RF scan new Client MAC: <macaddr>
AP MAC: <macaddr> Radio If: <int> detected
Informational
Wireless Client Association
detected
Wireless Client Association MAC: <macaddr>
VAP MAC: <macaddr> AP MAC: <macaddr>
SSID: <ssid> Security Mode: <string>
detected
Informational
Wireless Client Disassociation
detected
Wireless Client Disassociation MAC:
<macaddr> VAP MAC: <macaddr>AP MAC:
<macaddr> detected
Informational
Wireless Client Roam detected
Wireless Client Roam MAC: <macaddr> VAP
MAC: <macaddr> AP MAC:
<macaddr>detected
Informational
Wireless Client Association
Failure detected
Wireless Client MAC: <macaddr> Association
Failure detected
Warning
Wireless Client Authentication
Failure detected
Wireless Client MAC: <macaddr>
Authentication Failure detected
Warning
Wireless RF scan new Ad-Hoc
Client detected
Wireless RF scan new Ad-Hoc Client MAC:
<macaddr> AP MAC: <macaddr> Radio If:
<int> detected
Informational
Load Balacing
Wireless load balancing
utilization overflow
Wireless load balancing utilization overflow:
AP MAC: <macaddr> Radio If: <int> Radio
MAC: <macaddr> Utilization: <int>
Warning
Configuration
Push
Wireless peer Switch config
push command received
Wireless peer switch config push command
with mask <int> from switch: <ipaddr>
received
Informational
WIDS
Local Switch is elected as WIDS
Controller
Local Switch is elected as WIDS Controller
Informational
Wireless Network Managed AP
Max AP exceeded on WIDS
Controller
Wireless Network Managed AP Max AP
exceeded on WIDS Controller <ipaddr> when
AP MAC: <macaddr> with IP address <ipaddr>
connected to Wireless Switch <ipaddr>
Warning
Wireless rogue-AP(s) present in
the network
Wireless rogue-AP(s) present in the network
Informational
Wireless Detected client list full
Wireless Detected client list full
Warning
Wireless rogue-Client(s) present
in the network
Wireless rogue-Client(s) present in the
network
Informational
Auto Channel
& Power
Wireless Channel Algorithm is
complete
Wireless Channel Algorithm is complete
Informational
Wireless Power Algorithm is
complete
Wireless Power Algorithm is complete
Informational
Captive Portal CP Client Connected
CP Client Connected: MAC: <macaddr> IP:
<ipaddr> SwMAC: <macaddr> CPID: <int>
Interface: <int>
Informational
CP Client Disconnected
CP Client Disconnected: MAC: <macaddr> IP:
<ipaddr> SwMAC: <macaddr> CPID: <int>
Interface: <int>
Informational
