DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

264

Figure 11-87 CP-Client Status window

Use the drop-down menu to select a CP to see the information of the clients connected to the CP.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

SNMP Trap Configuration

This window is used to configure whether or not SNMP traps are sent from the Captive Portal and to specify

captive portal events that will generate a trap.

To view this window, click Security > Captive Portal (CP) > SNMP Trap Configuration as shown below:

Figure 11-88 SNMP Trap Configuration window

The fields that can be configured are described below:

Parameter Description

Client Authentication

Failure Traps

Use the drop-down menu to enable or disable the SNMP agent sending a trap when a

client attempts to authenticate with a captive portal but is unsuccessful.

Client Connection

Traps

Use the drop-down menu to enable or disable the SNMP agent sending a trap when a

client authenticates with and connects to a captive portal.

Client Database Full

Traps

Use the drop-down menu to enable or disable the SNMP agent sending a trap each

time an entry cannot be added to the client database because it is full.

Client Disconnection

Traps

Use the drop-down menu to enable or disable the SNMP agent sending a trap when a

client disconnects from a captive portal.

Click the Apply button to accept the changes made for each individual section.
