DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
488
wsAPFailureListFull
A wsAPFailureListFull trap signifies that the
SNMP entity, acting in an agent role, has
detected that AP failure list full.
1.3.6.1.4.1.171.12.96.11.0.6
wsRFScanAPListFull
A wsRFScanAPListFull trap signifies that the
SNMP entity, acting in an agent role, has
detected that RF scan AP list is full.
1.3.6.1.4.1.171.12.96.11.0.7
wsClientAssociationDatabaseFull
A wsClientAssociationDatabaseFull trap
signifies that the SNMP entity, acting in an
agent role, has detected that client association
database is full.
1.3.6.1.4.1.171.12.96.11.0.8
wsPeerSwitchDiscovered
A wsPeerSwitchDiscovered trap signifies that
the SNMP entity, acting in an agent role, has
detected peer Switch in the network.
1.3.6.1.4.1.171.12.96.11.0.9
wsPeerSwitchFailed
A wsPeerSwitchFailed trap signifies that the
SNMP entity, acting in an agent role, has
detected that peer Switch connection failed.
1.3.6.1.4.1.171.12.96.11.0.10
wsPeerSwitchUnknownProtocol
A wsPeerSwitchUnknownProtocol trap
signifies that the SNMP entity, acting in an
agent role, has detected unknown protocol
between wireless Switch and peer Switch
communication.
1.3.6.1.4.1.171.12.96.11.0.11
wsManagedAPDiscovered
A wsManagedAPDiscovered trap signifies that
the SNMP entity, acting in an agent role, has
detected the managed AP.
1.3.6.1.4.1.171.12.96.11.0.12
wsManagedAPFailed
A wsManagedAPFailed trap signifies that the
SNMP entity, acting in an agent role, has
detected the failed AP.
1.3.6.1.4.1.171.12.96.11.0.13
wsManagedAPUnknownProtocol
A wsManagedAPUnknownProtocol trap
signifies that the SNMP entity, acting in an
agent role, has detected the unknown protocol
between wireless Switch and managed AP
communication.
1.3.6.1.4.1.171.12.96.11.0.14
wsAPAssociationFailure
A wsAPAssociationFailure trap signifies that
the SNMP entity, acting in an agent role, has
detected that AP association failed.
1.3.6.1.4.1.171.12.96.11.0.15
wsAPAuthenticationFailure
A wsAPAuthenticationFailure trap signifies
that the SNMP entity, acting in an agent role,
has detected that AP authentication failed.
1.3.6.1.4.1.171.12.96.11.0.16
wsRFScanRogueAPDetected
A wsRFScanRogueAPDetected trap signifies
that the SNMP entity, acting in an agent role,
has detected Rogue AP through RF Scan.
1.3.6.1.4.1.171.12.96.11.0.17
wsRFScanAPDetected
A wsRFScanAPDetected trap signifies that
the SNMP entity, acting in an agent role, has
detected AP through RF Scan.
1.3.6.1.4.1.171.12.96.11.0.18
wsRFScanNewClientDetected
A wsRFScanNewClientDetected trap signifies
that the SNMP entity, acting in an agent role,
has detected new client through RF Scan.
1.3.6.1.4.1.171.12.96.11.0.19
wsClientAssociationDetected
A wsClientAssociationDetected trap signifies
that the SNMP entity, acting in an agent role,
has detected client association.
1.3.6.1.4.1.171.12.96.11.0.20
wsClientDisassociationDetected
A wsClientDisassociationDetected trap
signifies that the SNMP entity, acting in an
agent role, has detected client disassociation.
1.3.6.1.4.1.171.12.96.11.0.21
wsClientRoamDetected
A wsClientRoamDetected trap signifies that
the SNMP entity, acting in an agent role, has
detected client roaming.
1.3.6.1.4.1.171.12.96.11.0.22
wsClientAssociationFailure
A wsClientAssociationFailure trap signifies
that the SNMP entity, acting in an agent role,
has detected client association failure.
1.3.6.1.4.1.171.12.96.11.0.23
wsClientAuthenticationFailure
A wsAuthenticationFailure trap signifies that
the SNMP entity, acting in an agent role, has
detected client authentication failure.
1.3.6.1.4.1.171.12.96.11.0.24
wsAdHocClientDetected
A wsAdHocClientDetected trap signifies that
the SNMP entity, acting in an agent role, has
detected Ad hoc client.
1.3.6.1.4.1.171.12.96.11.0.25
wsWLANBandwidthUtilizationExceeded
A wsWLANBandwidthUtilizationExceeded trap
signifies that the SNMP entity, acting in an
1.3.6.1.4.1.171.12.96.11.0.26
