DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

204

Figure 11-17 Authenticator Diagnostics window

NOTE: The user must first globally enable Authentication Mode in the 802.1X Global Settings

window before initializing ports. Information in this window cannot be viewed before enabling

the authentication mode for either Port-based or MAC-based.

Initialize Port(s)

This window is used to display the authenticator diagnostics information. The window shows various information

based on the Authentication Mode configured in the 802.1X Global Settings window.

To view this window, click Security > 802.1X > Initialize Port(s) as shown below:

Figure 11-18 Initialize P Port(s) – Port-based window

The fields that can be configured are described below:

Parameter Description

From Port / To Port

Select a range of ports to be displayed.

Click the Apply button to accept the changes made.
