DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

465

Upload Log To TFTP

This page allows the user to upload the log file from the Switch to a TFTP Server.

Figure 2-9 Upload Log – TFTP window

The fields that can be configured are described below:

Parameter Description

TFTP Server IP

Enter the TFTP server IP address used.

IPv4

Click the radio button to enter the TFTP server IP address used.

IPv6

Click the radio button to enter the TFTP server IPv6 address

used.

Destination File

Enter the location and name of the Destination File.

Log Type Select the type of log to be transferred. Selecting the Common Log option here will

upload the common log entries. Selecting the Attack Log option here will upload the log

concerning attacks.

Click Upload to initiate the upload.

Upload Log To HTTP

This page allows the user to upload the log file from the Switch to a computer.

Figure 2-10 Upload Log – HTTP window

The fields that can be configured are described below:

Parameter Description

Log Type Here the user can select the type of log to be transferred. Selecting the Common

Log option here will upload the common log entries. Selecting the Attack Log option

here will upload the log concerning attacks.

Click Upload to initiate the upload.

Reset

The Reset function has several options when resetting the Switch. Some of the current configuration parameters

can be retained while resetting all other configuration parameters to their factory defaults.
