DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
144
Figure 9-12 QoS Scheduling Mechanism
The following parameters can be configured:
Parameter Description
From Port / To Port
Enter the port or port list you wish to configure.
Scheduling Mechanism Strict – The highest class of service is the first to process traffic. That is, the highest
class of service will finish before other queues empty.
Weighted Round Robin – Use the weighted round-robin algorithm to handle
packets in an even distribution in priority classes of service.
Click the Apply button to accept the changes made.
NOTE: The settings you assign to the queues, numbers 0-7, represent the IEEE 802.1p priority
tag number. Do not confuse these settings with port numbers.
