DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

160

B0,

B4,

B8,

B116,

B117

B120,

B121

B124,

B125

Example:

offset_chunk_1 0 0xffffffff will match packet byte offset 126,127,0,1

offset_chunk_1 0 0x0000ffff will match packet byte offset,0,1

NOTE: Only one packet_content_mask profile can be created.

With this advanced unique Packet Content Mask (also known as Packet Content Access Control List -

ACL), the D-Link switch family can effectively mitigate some network attacks like the

common ARP Spoofing attack that is wide spread today. This is why the Packet Content

ACL is able to inspect any specified content of a packet in different protocol layers.

Click the Select button to select an ACL type.

Click the Create button to create a profile.

Click the <<Back button to discard the changes made and return to the previous window.

After clicking the Show Details button, the following page will appear:

Figure 10-19 Access Profile Detail Information (Packet Content ACL)

Click the Show All Profiles button to navigate back to the Access Profile List Page.

NOTE: Address Resolution Protocol (ARP) is the standard for finding a host’s hardware address (MAC

address). However, ARP is vulnerable as it can be easily spoofed and utilized to attack a LAN

(i.e. an ARP spoofing attack). For a more detailed explanation on how ARP protocol works and

how to employ D-Link’s unique Packet Content ACL to prevent ARP spoofing attack, please

see Appendix E at the end of this manual.

After clicking the Add/View Rules button, the following page will appear:

Figure 10-20 Access Rule List (Packet Content ACL)

Click the Add Rule button to create a new ACL rule in this profile.

Click the <<Back button to return to the previous window.

Click the Show Details button to view more information about the specific rule created.

Click the Delete Rules button to remove the specific entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

After clicking the Add Rule button, the following page will appear:
