DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

248

Figure 11-68 CP configuration - CP Summary window

The fields that can be configured or displayed are described below:

Parameter Description

CP Configuration

Enter a name of CP configuration.

Configuration

Display the captive portal ID and name.

Mode

Display whether the CP is enabled.

Protocol

Display whether the portal uses HTTP or HTTPS.

Verification

Display which type of user verification to perform.

• Guest - The user does not need to be authenticated by a database.

• Local - The switch uses a local database to authenticated users.

• RADIUS - The switch uses a database on a remote RADIUS server to

authenticate users.

Languages

Display the number of languages that are configured for this captive portal.

Click the Add button to add a new entry based on the information entered.

Tick the check box of the specific entry, and click the Delete button to remove the specific entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

Click the link under Configuration in the table, or the tab to configure the detail information about CP configuration.

After clicking the link or the tab, the following page will appear:
