DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

262

Figure 11-84 Client Connection Status window

The fields that can be displayed are described below:

Parameter Description

Client IP Address

Display the IP address of the wired client (if applicable).

User Name

Display the user name (or Guest ID) of the connected client.

CP Configuration

Display the CP configuration the wired client is using.

Interface

Display the interface the wired client is using.

Protocol

Display the current connection protocol, which is either HTTP or HTTPS.

Verification

Display the current account type, which is Guest, Local, or RADIUS.

Session Time

Display the amount of time that has passed since the client was authorized.

Switch MAC Address

Display the MAC address of the switch handling authentication for this client. If

clustering issupported, this field might display the MAC address of a peer switch in

the cluster.

Switch Type

Display whether the switch handling authentication for this client is the local switch or

a peer switch in the cluster.

Switch IP Address

Display the IP address of the switch handling authentication for this client. If clustering

is supported, this field might display the IP address of a peer switch in the cluster.

Use the drop-down menu to select the MAC address of the associated client to view the detail information.

After clicking the Client Statistics tab, the following page will appear:
