DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

326

Figure 1-17 Client Summary window

The fields that can be displayed are described below:

Parameter Description

MAC Address

Display the MAC address of the wireless client (if applicable). If the MAC address is

marked with an asterisk (*), the authenticated client is authenticated by a peer switch.

In other words, the cluster controller was not the authenticator.

IP Address

Display the IP address of the wireless client (if applicable).

User

Display the user name (or Guest ID) of the connected client.

Protocol

Display the current connection protocol, which is either HTTP or HTTPS.

Verification

Display the current account type, which is Guest, Local, or RADIUS.

To force the captive portal to disconnect an authenticated client, select the corresponding check box next to the

client MAC address and click Delete.

To disconnect all clients from all captive portals, click Delete All.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

After clicking the Client Detail tab, the following page will appear:
