DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

338

After clicking the Hardware Type hyperlink or the Radio Detail tab under the AP Hardware Capability tab, the

following page will appear:

Figure 2-6 AP Hardware Capability - Radio Detail window

Use the drop-down menu to select the hardware type and click the radio buttons to select the radio index.

The fields that can be displayed are described below:

Parameter Description

Radio Count

Display the number of radios supported on the hardware platform, which is either 1

or 2.

Radio Type Description

Display the type of radio, which might contain information such as the manufacturer

name and supported IEEE 802.11 modes.

VAP Count

Display the number of VAPs the radio supports.

802.11a Support

Display whether support for IEEE 802.11a mode is enabled.

802.11bg Support

Display whether support for IEEE 802.11bg mode is enabled.

802.11n Support

Display whether support for IEEE 802.11n mode is enabled.

After clicking the Image Table tab under the AP Hardware Capability tab, the following page will appear:
