DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
346
is enabled), but it is not configured.
• Managed - The AP profile configuration has been applied to the AP and it's
operating in managed mode.
• Failed - The Unified Switch lost contact with the AP, a failed entry will remain in
the managed AP database unless you remove it. Note that a managed AP will
temporarily show a failed status during a reset.
NOTE: When management connectivity is lost for a managed AP, then both radios
of the AP are turned down. All the clients associated with the AP get
disassociated. The radios become operational if and when that AP is
managed again by a switch.
Software Version
Display the version of software on the AP. This is learned from the AP during
discovery.
Code Download Status
The current status of a code download request for this AP. The possible values are:
• Not Started - No download has begun.
• Requested - A download is planned for this AP, but the AP is not in the current
download group, so it hasn’t been told to start the download yet.
• Code-Transfer-In-Progress - The AP has been told to download the code.
• Failure - The AP reported a failing code download.
• Aborted - The download was aborted before the AP loaded code from the
TFTP server.
• Waiting-For-APs-To-Download - A download finished on this AP, and it is
waiting for other APs to finish download. Reset command is not sent to the AP
in this state.
• NVRAM-Update-In-Progress - Download completed successfully. The reset
command sent to the AP.
• Timed-Out - The AP did not reconnect to the Unified Switch in the fixed time
interval.
Configuration Status
Display whether the AP is configured successfully with the assigned profile. The
status is one of the following:
• Not Configured - The profile has not been sent to the AP yet, the AP may be
discovered but not yet authenticated.
• In Progress - The switch is currently sending the AP profile configuration
packet to the AP.
• Success - The entire profile has been sent to the AP and there were no
configuration errors.
• Partial Success - The entire profile has been sent to the AP and there were
configuration errors, but the AP is operational.
• Failure - The profile has been sent to the AP and there were configuration
errors, the AP is not operational.
Vendor ID
Vendor of the AP software, this is learned from the AP during discovery.
Part Number
Hardware part number for the AP, which is learned from the AP during discovery.
Hardware Type
Hardware platform for the AP, which is learned from the AP during discovery.
Managing Switch
Display whether the AP is managed by the local switch or a peer switch.
Switch MAC Address
The MAC address of the switch that is managing the AP.
Switch IP Address
The IP address of the switch that is managing the AP.
Profile
The AP profile configuration currently applied to the managed AP, the profile is
assigned to the AP in the valid AP database.
NOTE: Once an AP is discovered and managed by the Unified Switch, if the profile
is changed in the valid AP database (either locally or on the RADIUS
server) the AP must be reset to configure with the new profile.
Discovery Reason
This status value indicates how the managed AP was discovered, the status is one
of the following values:
