DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

350

The fields that can be displayed are described below:

Parameter Description

Neighbor AP MAC

The Ethernet MAC address of the neighbor AP network, this could be a physical

radio interface or VAP MAC address. For D-Link APs this is always a VAP MAC

address. The neighbor AP MAC address may be cross-referenced in the RF Scan

status.

SSID

Service Set ID of the neighbor AP network.

RSSI

Received Signal Strength Indication, this is an indicator of the signal strength

relative to the neighbor and may give an idea of the neighbor's distance from the

managed AP. The range is from 1 to 100, where 1 is the weakest signal strength.

Status

Indicate the managed status of the AP, whether this is a valid AP known to the

switch or a Rogue on the network. The valid values are:

• Managed - The neighbor AP is managed by the wireless system.

• Standalone - The AP is managed in standalone mode and configured as a valid

AP entry (local or RADIUS).

• Rogue - The AP is classified as a threat by one of the threat detection

algorithms.

• Unknown - The AP is detected in the network but is not classified as a threat by

the threat detection algorithms.

Age

Indicate the time since this AP was last reported from an RF scan on the radio.

Click the Neighbor AP MAC hyperlink to see the detail information about AP RF Scan Status.

Click the Delete All Neighbors to remove all the neighbor entries.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

After clicking the Neighbor Clients tab under the Status tab, the following page will appear:

Figure 2-18 Managed AP Status – Neighbor Clients window

Use the drop down menu to select AP’s MAC address and use the radio button to select a radio to view the

neighbor clients detected via an RF scan on that radio.

The fields that can be displayed are described below:

Parameter Description
